Description
Bruce RF Reaper PCB
Explore!
https://bruce.computer
MCU
ESP32 S3 N16R8
BATTERY 1000MAH
6 WAY BUTTON
AW9523 IO EXPANDER
NRF
CC1101 433MHZ
NFC ST25R3916
VIBRO
BUZZER
IR TX RX
IBUTTON
SDCARD
LED
GPS
FLIPPER ZERO HEADER COMPATIBLE
MULTIPLE UART AND I2C CONNECTIONS
Code
https://github.com/brucedevices/firmware
Feb 01,2026
3,069 views
Bruce RF Reaper PCB
Bruce RF Reaper is the new official Bruce Devices PCB, designed by Smoochiee
https://bruce.computer https://wiki.brunce.computer
3069
1
4
Published: Feb 01,2026
Standard PCB
BOM(Bill of materials)
Centroid file
PCBWay Donate 10% cost To Author
File Last Updated: 2026/02/26 (GMT+8)
File update record
2026-02-2611:22:18
Gerber file is updated.
Only PCB
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Copyright Info
CERN-OHL-P-2.0 License
Read More⇒
Under the
CERN-OHL-P-2.0
License.
